The KJG-81 Hollow Paddle Dryer features advanced technology design for chemical granules and intermediates processing. With 81 m² heat transfer area, 6.43 m³ effective volume, 5-15 r.p.m precision speed control, and 55 kW drive, it represents the cutting edge of large-scale chemical industry indirect drying.
| Model | KJG-81 Hollow Paddle Dryer |
| Heat Transfer Area | 81 m² |
| Effective Volume | 6.43 m³ |
| Revolution | 5-15 r.p.m |
| Power | 55 kW |
| Width of Dryer Body (A) | 1,828 mm |
| Total Width (B) | 2,286 mm |
| Length of Dryer Body (C) | 6,020 mm |
| Total Length (D) | 9,678 mm |
| Distance Inlet to Discharge (E) | 5,562 mm |
| Height in Center (F) | 1,220 mm |
| Total Height (G) | 2,464 mm |
| Steam Inlet (N) | (2) 1-1/2" |
| Water Outlet (O) | (2) 1-1/2" |
The KJG-81 delivers advanced technology drying for chemical granules and intermediates. Typical applications include: specialty chemical granule and prill drying, polymer and resin intermediate processing, catalyst precursor and support granule drying, agrochemical and pesticide intermediate dehydration, fine chemical granule and powder processing, and industrial chemical intermediate bulk drying. The advanced technology design ensures maximum product quality and consistency at the highest production volumes.
The KJG-81 features advanced technology specifically engineered for chemical granules and intermediates at industrial scale. With 81 m² heat transfer area, 6.43 m³ capacity, and precision 5-15 r.p.m control, it is the ultimate large-scale indirect drying solution for chemical manufacturers requiring maximum throughput, product quality, and process reliability.
